环境温度
Ambient temperature

℃

-25~50

电压波动范围
Voltage fluctuation range

%

85～110

额定功率
Rated power

W

56.3

额定行程
Rated stroke

mm

4.5

全行程
Full stroke

mm

≥ 4.5

工作油压
Working oil pressure

Mpa

≤ 30

防护等级
Degree of protection

IP54

操作频率
Operating frequency

T/h

12000

通电持续率
Power on duration

%

100

绝缘等级
Insulation class

H(180)

电气连接方式
Electrical connection mode

DT04-2P
