环境温度

Ambient temperature

℃

-25~50

额定电压

Rated voltage

VDC

12

24

额定功率

Rated power

W

20

额定电阻

Rated resistance

Ω

7.10

28.30

额定行程

Rated stroke

mm

1.9

额定行程

Rated stroke

mm

2.8

额定推力

Rated thrust

N

70

力滞环

Force hysteresis

%

≤4

电流滞环

Current hysteresis

%

≤4

重复精度

Repetition accuracy

%

≤1

工作油压

Working oil pressure

MPa

≤21

防护等级

Degree of protection

IP67

通电持续率

Power on duration

%

100

绝缘等级

Insulation class

H（180）

电气连接方式

Electrical connection mode

DT04-2P
